Technical Specifications
| Category | Specification |
|---|---|
| Product Number | 108-66003 |
| Product Type | Unshielded Twisted Pair (UTP) Outdoor |
| Category / Class | Cat.6 / Class E |
| Conductor | Solid Copper (assumed, spec not listed) |
| Number of Pairs | 4 Pairs (4P) |
| Water Blocking | Gel Filled (Jelly Filled) |
| Jacket Material | PE (Polyethylene) – Black |
| Jacket Thickness | 0.6mm |
| Standard Length | 305 Meters |
| Cable Diameter | 6.6mm ± 0.2mm |
Electrical Specifications:
-
Nominal Impedance: 100Ω ± 15% (1–250 MHz)
-
Max. Conductor DC Resistance: 9.38 Ω/100m at 20°C
-
Dielectric Strength: DC 500V / 1 min or AC 350V / 1 min
-
Insulation Resistance: 1500 MΩ·km at 20°C
Physical Specifications:
-
Minimum Bending Radius: 25mm
-
Max. Pulling Tension: 25 lbs
-
Jacket Elongation (Unaged): Min. 350%
