Applications:

• 1000BASE-TX / 1000BASE-T Gigabit Ethernet

• 100BASE-TX Fast Ethernet

• 10BASE-T Ethernet

• Voice, video, and multimedia applications

Technical Specifications:

Electrical Characteristics:

• Dielectric Strength: 1000V RMS for 1 minute

• Current Rating: 1.5 Amps Max.

• Insulation Resistance: 10MΩ Min.

• Contact Resistance: 2mΩ per contact

Physical & Material Properties:

• IDC Housing: Polycarbonate

• PCB Material: FR-4, UL94V-0 rated

• Contact Material: Phosphor bronze with 50µ inch gold plating over nickel in contact area

• Operating Temperature: -10°C to 60°C

• Humidity Range: 10% to 90% (non-condensing)

• Insertion Life: >2000 mating cycles
