Technical Specifications

Electrical Characteristics (Data Line):

• Transmission Rate: 1000 Mbps

• Nominal Voltage: 5V

• Maximum Continuous Operating Voltage (Uc): 7.8V

• Limit Voltage (Ur): 5V

• Nominal Discharge Current (In): 5kA (8/20µs)

• Maximum Discharge Current (Imax): 10kA (8/20µs)

• Response Time (Ta): 1 ns

• Insertion Loss (AE): ≤ 0.5 dB

Electrical Characteristics (Power Line):

• Continual Operating Voltage: 220V

• Max Continual Voltage: 380V

Physical Properties:

• Connector: RJ45

• Protected Pins: 1, 2, 3, 6

• Dimensions (Power Unit): 80 x 25 x 25 mm

• Design: Compact for easy installation

Applications:

• Network Infrastructure

• Data Centers and Server Rooms

• Smart Buildings and IoT Systems

• Telecommunications

• Surge Protection for Critical Systems.

Product Highlights

• Dual Protection: Safeguards both Ethernet (data) and power lines from lightning strikes and voltage surges.

• High-Speed Performance: Supports data transmission rates up to 1000Mbps with minimal impact on signal quality.

• Ultra-Fast Response: Reacts to surges in just 1 nanosecond (1ns) to protect connected equipment instantly.

• Robust Protection: Withstands surge currents up to 10kA, using high-quality, international brand components.

• Compact & Easy to Install: Small form factor for space-efficient and simple integration into any setup.
