Interfaces
| Inputs/Outputs | 12 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) PoE 12 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) 2 x 10/100/1000 Mb/s Gigabit SFP |
Protocols
| Layer Services Supported | Layer 2 Support |
| Supported Protocols | Auto-MDIX/MDI IGMP Snooping Link Aggregation Port Mirroring |
| MAC Address Table Size | 16K |
Security
| Security Features | DoS Attack Prevention Storm Control |
Standards
| Supported IEEE Standards | 802.1ab, 802.1d, 802.1p, 802.1q, 802.1w, 802.3, 802.3ab, 802.3ac, 802.3ad, 802.3af, 802.3at, 802.3az, 802.3u, 802.3x, 802.3z |
Performance
| Latency | 2.8 to 5.2 µs |
| Forwarding Rate | 38.68 Mpps |
| Switching Bandwidth | 52 Gb/s |
| Packet Buffer | 1.5 MB |
Computer
| Flash Memory | 256 MB |
| CPU | Up to 800 MHz A9 Single-Core |
| Memory | 512 MB |
Electrical
| Power Draw | 237.2 W (Max) 13.4 W (Idle) |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz at 1.4 to 2.7 A |
| PoE Power Budget | 195 W |
| PoE per Port | 30 W |
| Power Supply Type | Internal |
Environmental
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Operating Humidity | 15 to 95% |
| Storage Temperature | -40 to 158°F / -40 to 70°C |
| Storage Humidity | 15 to 95% |
| Operating Altitude | 10,000′ / 3048 m |
| Noise Level | 17.0 dB |
General
| Cooling System | Fan |
| Mean Time Between Failures (MTBF) | 846,216 Hours |
| Rack Form Factor | 1 RU |
| Dimensions | 17.4 x 10 x 1.7″ / 443 x 253 x 43.9 mm |
| Weight | 7.65 lb / 3.47 kg |
Packaging Info
| Package Weight | 10.825 lb |
| Box Dimensions (LxWxH) | 20.8 x 15.6 x 5.2″ |
