Specifications

Specification	Details
Brand	Huawei
Country / Brand Origin	China
Product Series	eKitEngine S110 Series
Model	S110-16T2S
Part Number	98012200
Product Type	Unmanaged Gigabit Ethernet Switch
PoE Support	No – Non-PoE
Ethernet Ports	16 × 10/100/1000BASE-T RJ45
SFP Ports	2 × GE SFP
Total Network Ports	18
Switching Capacity	36 Gbit/s
Packet Forwarding Rate	26.78 Mpps
MAC Address Table	8K Entries
Chassis Material	Metal
Cooling System	Fanless / Natural Heat Dissipation
Static Power Consumption	3 W
Typical Power Consumption	11 W
Maximum Power Consumption	12 W
Power Supply	Built-in AC Power Supply
Input Voltage	90–264 V AC, 45–65 Hz
Dimensions (H × W × D)	43.6 × 320 × 210 mm
Weight	Approx. 1.74 kg
Installation	Desktop / Wall Mount / Rack Mount
Operating Temperature	0°C to 40°C at 0–1800 m altitude
Operating Humidity	5%–95% RH, Non-Condensing
Management Type	Unmanaged
Heat Dissipation	Natural Heat Dissipation

High-Speed Gigabit Networking

The Huawei S110-16T2S provides 16 Gigabit Ethernet RJ45 ports, allowing multiple network devices to communicate at speeds of up to 1 Gbit/s per Ethernet port. It is suitable for connecting desktop computers, servers, printers, network storage devices, IP cameras, wireless access points and other Ethernet-enabled equipment.

Its 36 Gbit/s switching capacity and 26.78 Mpps packet forwarding rate help provide efficient data transmission across a busy business network.

Dual GE SFP Fiber Uplink Ports

The switch includes 2 × Gigabit SFP ports, providing flexible fiber uplink connectivity when used with compatible SFP transceiver modules.

These fiber uplinks are particularly useful for:

• Connecting switches between different floors
• Extending network connections over longer distances
• Connecting to a central network distribution switch
• Office and commercial building networks
• Fiber backbone connections
• Separating access switches from core network equipment

Plug-and-Play Unmanaged Operation

The Huawei eKitEngine S110-16T2S is an unmanaged switch, making installation simple. Network cables can be connected directly to the switch without requiring complicated software configuration.

This makes it particularly suitable for businesses that require reliable network expansion without the additional complexity of a fully managed switch.

Fanless Silent Design

The S110-16T2S uses natural heat dissipation without a cooling fan. This reduces operating noise and eliminates the mechanical wear associated with cooling fans, making the switch well suited to office and other noise-sensitive environments.

Flexible Installation

The Huawei S110-16T2S supports:

• Desktop Installation
• Wall Mounting
• Rack Mounting

Its compact metal chassis measures approximately 43.6 × 320 × 210 mm, allowing it to be installed conveniently in network cabinets, communication rooms and office environments.

Suitable Applications

The Huawei eKitEngine S110-16T2S is ideal for:

• Small and Medium-Sized Businesses
• Corporate Offices
• Retail Stores
• Commercial Buildings
• Schools and Educational Institutions
• CCTV and IP Surveillance Networks
• Computer Networks
• Wireless Access Point Networks
• Network Storage and NAS Connectivity
• Fiber-Connected LAN Extensions
• Office Network Expansion
