Applications Supported:

• Voice and JSON

• 10BASE-T, Fast Ethernet, Gigabit Ethernet (1000BASE-T)

• Token Ring, 100VG-AnyLAN, ATM (155/622 Mbps)

• Broadband Video (up to 550 MHz)

• TP-PMD and other legacy protocols (with suitable adapters)

Standards Compliance:

• UL and ETL verified

• Compliant with ANSI/TIA-568-2.D, ISO/IEC 11801, EN 50173

Specifications:

• Product Number: 1402-03019

• Product Name: 1U 24 Port Cat.5e UTP Patch Panel, Component level

• Ports: 24

• Rack Size: 1U, 19-inch standard

• Termination Type: IDC (110 / Krone compatible)

• Frame Material: Cold rolled steel (SPCC-SD 16G)

• Contacts: Phosphor bronze with nickel underplating and 50µ” gold plating

• Operating Temperature: -10°C to +60°C

• Insertion/Extraction Life: 750 cycles minimum
