Specification
| Camera | ||
| Image Sensor | 1/3″ Progressive Scan CMOS | |
| Resolution | 2560 × 1440 | |
| Shutter Speed | 1/3 s to 1/100,000 s | |
| Day & Night | IR cut filter | |
| Min. Illumination | Color: 0.001 Lux @ (F1.0, AGC ON) | |
| SNR (dB) | ≥ 52 dB | |
| Angle Adjustment | Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360° | |
| Lens | ||
| Lens Type | Fixed focal | |
| Lens Mount | M12 | |
| Focal Length | 2.8mm | |
| Aperture | F1.0 | |
| Field of View | 2.8 mm, horizontal FOV 115°, vertical FOV 60°, diagonal FOV 143° 4 mm, horizontal FOV 94°, vertical FOV 50°, diagonal FOV 110° | |
| Iris Type | Fixed | |
| DORI Distance | 2.8 mm, D: 64 m, O: 25 m, R: 12 m, I: 6 m 4 mm, D: 77 m, O: 30 m, R: 15 m, I: 7 m | |
| Illuminator | ||
| IR LEDs | IR, White Light | |
| IR Distance | Up to 30 m | |
| IR Wavelength | 850 nm | |
| Video | ||
| Video Compression | Main stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG | |
| Main Stream | 50 Hz: 20 fps (2560 × 1440) 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 20 fps (2560 × 1440) 24 fps (1920 × 1080, 1280 × 720) | |
| Sub Stream | 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 24 fps (1280 × 720, 640 × 480, 640 × 360) | |
| Video Frame Rate | Main Stream: 50 Hz: 20 fps (2560 × 1440) 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 20 fps (2560 × 1440) 24 fps (1920 × 1080, 1280 × 720) Sub-Stream: 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 24 fps (1280 × 720, 640 × 480, 640 × 360) |
|
| Bit Rate Control | CBR, VBR | |
| Video Bit Rate | 32 Kbps to 16 Mbps | |
| Day/Night | Auto, Schedule | |
| BLC | Yes | |
| HLC | Yes | |
| WDR | 3D DNR | |
| Region of Interest (ROI) | 1 fixed region for main stream | |
| Mirror | Yes | |
| Privacy Masking | 4 programmable polygon privacy masks | |
| Others | 3D DNR | |
| Audio | ||
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC | |
| Audio Bitrate | 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC) | |
| Built-in Microphone | Yes,1 built-in microphone | |
| Environment Noise Filtering | Yes | |
| Audio Sampling Rate | 8 kHz/16 kHz | |
| Audio Bit Rate | 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC) | |
| Storage | ||
| Card Slot | Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB | |
| Network | ||
| Protocol | IPv4, IPv6, TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IGMP, UDP, QoS, FTP, SMTP | |
| Simultaneous Live View | Up to 6 channels | |
| API | Open Network Video Interface (Profile S, Profile T, Profile G (only -F model supports)),ISAPI,SDK | |
| User/Host | Up to 32 users 3 user levels: administrator, operator, and user | |
| Client | iVMS-4200,Hik-Connect | |
| Web Browser | Plug-in required live view: IE 10, IE 11, Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+ | |
| Interface | ||
| Network Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port | |
| Alarm | ||
| Basic Detection | Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception | |
| Environment | ||
| Storage Temperature | -30 °C to 60 °C (-22 °F to 140 °F) | |
| Storage Humidity | Humidity 95% or less (non-condensing) | |
| Water Protection | IP67 | |
| Power | ||
| Power Supply | 12 VDC ± 25%, 0.5 A, max. 6 W,Ø5.5 mm coaxial power plug,reverse polarity protection, PoE: IEEE 802.3af, Class 3, max. 7.5 W | |
| PoE Standard | IEEE 802.3af | |
| Physical Information | ||
| Casing Material | Front cover: metal, body: plastic, bracket: plastic | |
| Dimension | 69.8 mm × 67.9 mm × 172.9 mm (2.7″ × 2.7″ × 6.8″) | |
| Weight | Approx. 550 g (1.2 lb.) | |
| Warranty Information | ||
| Warranty | 2 Year | |
