Specification
| General | ||
| Dimensions | Ø110 mm × 89.2 mm (Ø4.3″ × 3.5″) | |
| Weight | Approx. 340 g (0.7 lb.) | |
| Pan/Tilt/Rotation | Pan: 0° to 360°,tilt: 0° to 75°,rotate: 0° to 360° | |
| Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) | |
| Power Supply | 12 VDC ± 25%, 0.4 A, max. 5 W,Ø5.5 mm coaxial power plug,reverse polarity protection, PoE: IEEE 802.3af, Class 3, max. 6.5 W | |
| Camera | ||
| Image Sensor | 4MP 1/3″ Progressive Scan CMOS | |
| Effective Pixels | 2560 × 1440 | |
| Minimum Illumination | Color: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR | |
| IR Distance | 30 m | |
| Lens | ||
| Lens Type | 2.8 mm fixed focal lens | |
| Mount Type | M12 | |
| Focal Length | 2.8 mm, horizontal FOV 98°, vertical FOV 54°, diagonal FOV 114° | |
| Max Aperture | F1.6 | |
| Video | ||
| Frame Rate | Main Stream 50 Hz: 20 fps (2560 × 1440) 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 20 fps (2560 × 1440) 24 fps (1920 × 1080, 1280 × 720) Sub-Stream 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 24 fps (1280 × 720, 640 × 480, 640 × 360) |
|
| Day/Night | Color | |
| Interface | ||
| Audio Interface | Audio Type: Mono sound Environment Noise Filtering: Yes Audio Sampling Rate: 8 kHz/16 kHz Audio Compression: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC Audio Bit Rate: 64 Kbps (G.711 ulaw)/64 Kbps (G.711 alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC) |
|
| Warranty | ||
| Warranty | 02 year warranty | |
