Specification
| Camera Feature | ||
| Image Sensor | 1/2.8″ Progressive Scan CMOS | |
| Effective Pixels | 6MP | |
| IR Distance | Up to 50 m | |
| Others | Max. Resolution: 3200 × 1800 Min. Illumination: Color: 0.001 Lux @ (F1.0, AGC ON), 0 Lux with light Shutter Time: 1/3 s to 1/100, 000 s Day & Night: IR cut filter Angle Adjustment: Pan: 0° to 355°,tilt: 0° to 180°,rotate: 0° to 355°DORI 4 mm, D: 77 m, O: 30 m, R: 15 m, I: 7 mIlluminator Supplement Light Type IR,White Light Supplement Light Range Up to 50 m Smart Supplement Light Yes IR Wavelength 850 nm Video Main Stream 50 Hz: 20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) Sub-Stream 50 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360) Video Compression Main stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG Video Bit Rate 32 Kbps to 16 Mbps H.264 Type Baseline Profile,Main Profile,High Profile H.265 Type Main Profile Bit Rate Control CBR,VBR Scalable Video Coding (SVC) H.264 and H.265 encoding Region of Interest (ROI) 1 fixed region for main stream Audio Audio Type Mono sound Audio Compression G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC Audio Bit Rate 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC) Audio Sampling Rate 8 kHz/16 kHz Environment Noise Filtering Yes Image Image Settings Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser Day/Night Switch Day,Night,Auto,Schedule Wide Dynamic Range (WDR) 120 dB SNR ≥ 52 dB Image Enhancement BLC,HLC,3D DNR Privacy Mask 4 programmable polygon privacy masks |
|
| Lens | ||
| Type | 4mm | |
| Focal Length | Fixed focal lens | |
| Aperture | F1.0 | |
| Angle of View | 2.8 mm, horizontal FOV 115°, vertical FOV 60°, diagonal FOV 143° 4 mm, horizontal FOV 94°, vertical FOV 50°, diagonal FOV 110° |
|
| Others | Lens Mount M12 Iris Type Fixed |
|
| Physical Specification | ||
| Dimension | 81 mm × 83.7 mm × 201.96 mm (3.17″ × 3.29″ × 7.95″) | |
| Weight | Approx. 550 g (1.2 lb.) With Package Weight Approx. 800 g (1.8 lb.) |
|
| Power | 12 VDC ± 25%, 0.6 A, max. 7.2 W, Ø 5.5 mm coaxial power plug, reverse polarity protection, PoE: IEEE 802.3af, Class 3, max. 8.7 W |
|
| Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB built-in microphone |
|
| Others | Protocols IPv4，IPv6，TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IGMP, UDP, QoS, FTP, SMTP, UPnP Simultaneous Live View Up to 6 channels API Open Network Video Interface (Profile S, Profile T, Profile G (only -F model supports)),ISAPI,SDK User/Host Up to 32 users 3 user levels: administrator, operator, and user Security Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address) Client iVMS-4200,Hik-Connect Web Browser Plug-in required live view: IE 10, IE 11, Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+ |
|
| Warranty | ||
| Warranty | 2 Year | |
