| AI by Device |
Facial recognition, perimeter protection, motion detection 2.0 |
| AI by Camera |
Facial recognition, perimeter protection, throwing objects from building, motion detection 2.0, ANPR, VCA |
| Perimeter Protection by Device |
2-ch, 4 MP HD network camera, H.264/H.265 video analysis for human and vehicle recognition to reduce false alarms |
| Perimeter Protection by Camera |
All channels |
| Facial Detection and Analytics |
Face picture comparison, human face capture, face picture search |
| Face Picture Library |
Up to 16 face picture libraries, up to 20,000 face pictures in total. Each picture ≤ 4 MB, total capacity ≤ 1 GB |
| Facial Detection and Analytics Performance |
1-ch, 8 MP |
| Face Picture Comparison |
4-ch |
| Motion Detection 2.0 by Device |
All channels, 4 MP video analysis for human and vehicle recognition to reduce false alarms. When enhanced SVC mode is enabled, up to 8 MP |
| Motion Detection 2.0 by Camera |
All channels |
| IP Video Input |
32-ch |
| Incoming Bandwidth |
256 Mbps |
| Outgoing Bandwidth |
160 Mbps |
| HDMI Output |
1-ch, 4K 3840 × 2160/30 Hz, 2K 2560 × 1440/60 Hz, 1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz |
| VGA Output |
1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz |
| Video Output Mode |
HDMI/VGA independent output |
| CVBS Output |
N/A |
| Audio Output |
1-ch, RCA, 2.0 Vp-p, 1 KΩ, using the audio input |
| Two-Way Audio |
1-ch, RCA, Linear, 1 KΩ |
| Decoding Format |
H.265/H.265+/H.264+/H.264 |
| Recording Resolution |
12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Synchronous Playback |
16-ch |
| Decoding Capability – AI On |
1-ch@12 MP 30 fps / 2-ch@8 MP 30 fps / 4-ch@4 MP 30 fps / 8-ch@1080p 30 fps |
| Decoding Capability – AI Off |
2-ch@12 MP 30 fps / 3-ch@8 MP 30 fps / 6-ch@4 MP 30 fps / 12-ch@1080p 30 fps |
| Smooth Playback HC ON & AI ON |
1-ch@12 MP 30 fps / 1-ch@8 MP 30 fps / 3-ch@4 MP 30 fps / 7-ch@1080p 30 fps |
| Smooth Playback HC ON & AI OFF |
1-ch@12 MP 30 fps / 2-ch@8 MP 30 fps / 5-ch@4 MP 30 fps / 11-ch@1080p 30 fps |
| Stream Type |
Video, Video & Audio |
| Audio Compression |
G.711ulaw/G.711alaw/G.722/G.726/AAC |
| Remote Connection |
128 |
| API |
ONVIF Profile S/G, SDK, ISAPI |
| Compatible Browser |
IE11, Chrome V57, Firefox V52, Safari V12, Edge V89 or above |
| Network Protocol |
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS |
| Network Interface |
1 × RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
| SATA |
2 SATA interfaces |
| HDD Capacity |
Up to 16 TB capacity for each HDD |
| USB Interface |
Front panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0 |
| Alarm In/Out |
4/1 |
| GUI Language |
English, |
| Power Supply |
12 VDC, 3.3 A |
| Consumption |
≤ 15 W without HDD |
| Working Temperature |
-10 °C to 55 °C / 14 °F to 131 °F |
| Working Humidity |
10% to 90% |
| Dimensions W × D × H |
385 mm × 315 mm × 52 mm / 15.2″ × 12.4″ × 2.0″ |
| Weight |
≤ 1 kg without HDD / 2.2 lb |
| FCC |
Part 15 Subpart B, ANSI C63.4-2014 |
| CE |
EN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035:2017 |
| Obtained Certification |
CE, FCC, IC, CB, KC, UL, RoHS, REACH, WEEE, RCM, UKCA, LOA, BIS |
