Specification
| Audio and Video | ||
| IP Camera Input | Up to 24-ch IP camera inputs, each channel up to 6MP | |
| Two-Way Talk | Support All channels HDTVI Two-Way Audio Technology | |
| Recording | ||
| Compression | H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 | |
| Resolution | When 1080p Lite mode is not enabled: 2K/3K lite/5 MP lite/4 MP lite/1080p/720p/VGA/WD1/4CIF/CIF; When 1080p Lite mode is enabled: 2K/3K lite/5 MP lite/4 MP lite/1080p lite/720p lite/VGA/WD1/4CIF/CIF | |
| Bit Rate | 32 Kbps to 6 Mbps | |
| Video Detection And Alarm | ||
| Video Detection | Yes | |
| Alarm Input | Yes | |
| Playback And Backup | ||
| Sync Playback | 16-ch | |
| Network | ||
| Interface | 1, RJ45 10/100/1000 Mbps self-adaptive Ethernet interface | |
| Storage | ||
| HDD Mode | 16 channels and 2 HDDs 1U AcuSense DVR | |
| Auxiliary Interface | ||
| USB | Front panel: 1 × USB 2.0; Rear panel: 2 × USB 3.0 |
|
| Power | ||
| Power Supply | 12 VDC, 2 A | |
| Power Consumption | ≤ 24 W | |
| Construction | ||
| Dimensions | 319 × 240 × 48 mm (12.6 × 9.4 × 1.9 inch) | |
| Net Weight | ≤ 2 kg (4.4 lb) | |
| Warranty | ||
| Manufacturing Warranty | 02 Year Warranty (Without Adapter) | |
