Specifications
| Specification | Details |
|---|---|
| Brand | Huawei |
| Brand Origin | China |
| Product Series | eKitEngine S110 Series |
| Model | S110-24T2SR |
| Part Number | 98012196 |
| Product Type | Unmanaged Gigabit Ethernet Switch |
| PoE Support | No – Non-PoE |
| Ethernet Ports | 24 × 10/100/1000BASE-T RJ45 |
| SFP Ports | 2 × GE SFP |
| Total Physical Ports | 26 |
| Maximum GE Ports | 26 |
| Switching Capacity | 52 Gbit/s |
| Packet Forwarding Rate | 38.69 Mpps |
| Power Supply | Built-in AC Power Supply |
| Rated Input Voltage | 100–240 V AC, 50/60 Hz |
| Input Voltage Range | 90–264 V AC, 45–65 Hz |
| Maximum Input Current | 0.8 A |
| Static Power Consumption | 5 W |
| Typical Power Consumption | 16 W |
| Maximum Power Consumption | 17 W |
| Cooling System | Fanless / Natural Heat Dissipation |
| Chassis Height | 1U |
| Dimensions (H × W × D) | 43.6 × 442 × 160 mm |
| Maximum Device Depth | 167 mm |
| Weight | Approx. 1.8 kg |
| Installation | Rack Mount / Desktop / Wall Mount |
| Operating Temperature | 0°C to 40°C at 0–1800 m altitude |
| Storage Temperature | -40°C to +70°C |
| Operating Humidity | 5%–95% RH, Non-Condensing |
| Operating Altitude | Up to 5000 m |
| Heat Dissipation | Natural Heat Dissipation |
Key Features
- Huawei eKitEngine S110 Series
- Model: S110-24T2SR
- Part Number: 98012196
- 24 × 10/100/1000BASE-T Gigabit Ethernet RJ45 Ports
- 2 × GE SFP Ports
- 26 Total Physical Network Ports
- Non-PoE Model
- Unmanaged / Plug-and-Play Network Switch
- 52 Gbit/s Switching Capacity
- 38.69 Mpps Packet Forwarding Rate
- Built-in AC power supply
- Fanless natural heat dissipation
- Quiet operation
- 1U chassis height
- Supports rack, desktop and wall mounting
- Suitable for commercial and professional network environments
High Network Performance
The Huawei S110-24T2SR provides a 52 Gbit/s switching capacity and a 38.69 Mpps packet forwarding rate, allowing it to efficiently handle traffic from multiple connected Gigabit devices.
This makes it suitable for everyday commercial applications involving file transfers, internet access, network storage, surveillance traffic, office applications and other data-intensive network operations.
Plug-and-Play Unmanaged Design
As an unmanaged network switch, the S110-24T2SR is designed for straightforward deployment without complicated configuration.
Connect the power supply and network cables, and the switch can be integrated into a standard Ethernet network. This makes it suitable for businesses that require dependable Gigabit network expansion without the management complexity associated with advanced managed switches.
Fanless Quiet Operation
The Huawei eKitEngine S110-24T2SR uses natural heat dissipation, eliminating the need for an internal cooling fan.
The fanless design provides:
- Quiet operation
- No fan noise in office environments
- Fewer moving components
- Reduced fan-related maintenance
- Suitability for noise-sensitive workplaces
Flexible Installation
The S110-24T2SR has a 1U chassis measuring approximately 43.6 × 442 × 160 mm and supports:
- 19-inch Rack Mounting
- Desktop Installation
- Wall Mounting
This allows the switch to be deployed in network cabinets, equipment rooms, office environments or other suitable network locations. Huawei lists the unit at approximately 1.8 kg without packaging.
Suitable Applications
The Huawei eKitEngine S110-24T2SR is suitable for:
- Small and Medium-Sized Businesses
- Corporate Offices
- Commercial Buildings
- Retail Stores
- Schools and Educational Institutions
- Computer Labs
- CCTV and IP Surveillance Networks
- Network Storage Environments
- Office LAN Expansion
- Fiber Backbone Connections
- Wireless Access Point Networks
- Multi-Floor Business Networks
Power and Energy Consumption
The switch features a built-in AC power supply with a rated input of 100–240 V AC, 50/60 Hz.
Power consumption is:
- Static: 5 W
- Typical: 16 W
- Maximum: 17 W
This makes the S110-24T2SR relatively energy-efficient for a 24-port Gigabit network switch.
Complete your network connections
Match cable performance to the installation and check the exact switch interfaces before choosing accessories.
