Specification

Specification	Details
Brand	Huawei
Product Series	eKitEngine S110 Series
Model	S110-8T2ST
Part Number	98012199
Product Type	Unmanaged Gigabit Ethernet Switch
PoE Support	No – Non-PoE
Downlink Ports	8 × 10/100/1000BASE-T RJ45
RJ45 Uplink Port	1 × 10/100/1000BASE-T
Optical Uplink Port	1 × GE SFP
Total Physical Network Ports	10
Switching Capacity	20 Gbit/s
Packet Forwarding Rate	14.88 Mpps
MAC Address Table	4K entries
Working Modes	Standard Mode / Port Isolation / Flow Control Disabling
Cooling System	Fanless
Heat Dissipation	Natural heat dissipation
Power Supply	External AC power adapter
Switch Power Input	12 V DC
Maximum Input Current	1 A
Maximum Power Consumption	Approx. 8 W
Dimensions (H × W × D)	35 × 210 × 130 mm
Operating Temperature	0°C to 40°C at 0–1800 m altitude
Storage Temperature	-40°C to +70°C
Operating Humidity	5% to 95% RH, non-condensing
Installation	Desktop / Wall Mount
Management	Unmanaged
Console Port	Not Supported
USB Port	Not Supported

Key Features

• Huawei eKitEngine S110 Series
• Model: S110-8T2ST
• Part Number: 98012199
• Unmanaged / Plug-and-Play Network Switch
• Non-PoE Design
• 8 × 10/100/1000BASE-T Gigabit Ethernet Ports
• 1 × 10/100/1000BASE-T Gigabit RJ45 Uplink Port
• 1 × GE SFP Optical Uplink Port
• 20 Gbit/s Switching Capacity
• 14.88 Mpps Packet Forwarding Rate
• Supports copper and fiber uplink connectivity
• Three selectable working modes
• Fanless natural heat dissipation
• Compact desktop or wall-mountable design
• Suitable for SMB, office and commercial networks

Working Modes

Standard Mode

All ports operate within the same network, with flow control enabled. This mode is suitable for normal office and general LAN applications.

Port Isolation Mode

The eight downlink ports are isolated from one another and communicate through the uplink ports. This can help improve network isolation for applications such as IP surveillance and shared business networks.

Flow Control Disabling Mode

All ports remain within the same network while Ethernet flow control is disabled.

Gigabit + Fiber Connectivity

The S110-8T2ST provides eight Gigabit Ethernet access ports for computers, printers, network storage, IP cameras, wireless access points and other Ethernet devices.

In addition, the switch provides two dedicated uplink options:

1 × GE RJ45 Uplink – ideal for connecting to routers, gateways or another Ethernet switch using standard network cabling.

1 × GE SFP Uplink – allows compatible SFP optical modules to be used for fiber network connections, making the switch suitable for extending networks between floors, offices or network distribution locations.

Fanless and Quiet Operation

The Huawei eKitEngine S110-8T2ST uses a fanless natural heat-dissipation design. With no internal cooling fan, the switch operates quietly and reduces the number of moving components, making it suitable for offices, reception areas, shops and other noise-sensitive environments.

Suitable Applications

The Huawei S110-8T2ST is suitable for:

• Small and medium-sized business networks
• Office LAN expansion
• Retail shops and commercial environments
• IP CCTV and surveillance networks
• Network printers and NAS devices
• Wireless access point connectivity
• Fiber-connected network extensions
• Schools and educational institutions
• SOHO and professional office environments
