Specifications
| Specification | Details |
|---|---|
| Brand | Level One |
| Model | GEU-0521 |
| Product Type | Gigabit Ethernet Network Switch |
| Switch Type | Unmanaged |
| Total Ports | 5 |
| Gigabit RJ45 Ports | 4 × 10/100/1000Mbps |
| SFP Slots | 1 × Gigabit SFP |
| SFP Standard | 1000BASE-X |
| Switching Capacity | 10Gbps |
| Backplane Capacity | 10Gbps |
| Jumbo Frame | Up to 9KB |
| MAC Address Table | 4K Entries |
| MAC Learning | Automatic |
| MAC Aging | Automatic |
| Transmission Method | Store-and-Forward |
| Auto-Negotiation | Yes |
| Auto-MDI/MDIX | Yes |
| Flow Control | IEEE 802.3x |
| Full Duplex | Supported |
| 1000Mbps Forwarding Rate | 1,488,000 packets/sec |
| 100Mbps Forwarding Rate | 148,800 packets/sec |
| 10Mbps Forwarding Rate | 14,880 packets/sec |
| PoE Support | No |
| Manageable | No |
| Cooling | Fanless |
| LED Indicators | Power, Link/Activity, Speed |
| Installation | Desktop / Wall Mount |
| Power Input | 5V DC, 2A |
| External Power Input | 100–240V AC, 50/60Hz |
| Power Consumption | Less than 6W |
| Power Adapter Included | Yes |
| Dimensions (W × D × H) | 96 × 112 × 30mm |
| Product Weight | Approx. 0.38kg |
| Colour | Black |
| EAN / GTIN | 4015867173480 |
Network Standards
- IEEE 802.3 – 10BASE-T Ethernet
- IEEE 802.3u – 100BASE-TX Fast Ethernet
- IEEE 802.3ab – 1000BASE-T Gigabit Ethernet
- IEEE 802.3z – 1000BASE-X Gigabit Ethernet
- IEEE 802.3x – Full-Duplex Flow Control
Ideal For
The Level One GEU-0521 is suitable for:
- Small and medium business networks
- Office network expansion
- Fibre uplink applications
- Connecting separate network locations
- Network servers
- NAS and network storage
- IP surveillance networks
- NVR and CCTV infrastructure
- Wireless access points
- Desktop computers
- Network printers
- Routers and gateways
- Gigabit network backbone connections
- Copper-to-fibre network integration
Package Contents
- 1 × Level One GEU-0521 5-Port Gigabit Switch
- 1 × External Power Adapter
- 1 × User Manual
