Specifications
| Model | POS-5000 |
|---|---|
| Product type | Gigabit high-power PoE splitter |
| Ethernet data rate | 10/100/1000 Mbps |
| PoE input standards | IEEE 802.3af/at/bt |
| DC output | Selectable 12 V or 24 V via DIP switch |
| Maximum output power | Up to 60 W |
| Protection | Short-circuit protection |
| Indicators | Power, Link/Act |
| Dimensions | 80 × 53 × 24 mm |
| Product weight | 0.08 kg |
| Operating temperature | 0 °C to 40 °C |
| Operating humidity | 5% to 90% RH |
| Package contents | Power cable and RJ45 cable listed by manufacturer |
Key Features
- Run a non-PoE device from a compatible high-power PoE network connection without a nearby outlet.
- Split a Gigabit PoE input into separate Ethernet data and DC power outputs.
- Select a 12 V or 24 V output to match supported device requirements.
- Supply up to 60 W to suitable equipment, subject to the available PoE input and device load.
- Use built-in short-circuit protection and Power/Link activity indicators for practical deployment.
Product Information
The Level One POS-5000 separates a compatible IEEE 802.3bt PoE network feed into Gigabit Ethernet data and DC power for a device without its own PoE input. It is intended for equipment such as a compatible camera or access point that requires either 12 V or 24 V DC. Set the DIP switch to the voltage specified on the connected device before powering it; the device must also accept the connector and remain within the splitter’s 60 W maximum and the available upstream PoE budget. The manufacturer lists a power cable and RJ45 cable in the package. A PoE injector or PoE switch is required upstream and is not listed as included.
