Specifications
| Brand / origin | Level One / Germany |
|---|---|
| Model | GVT-2002 |
| Documented hardware revision | 1 |
| Copper interface | 1 × 10/100/1000BASE-T RJ45; auto MDI/MDI-X and auto-negotiation |
| Fiber interface | Duplex SC single-mode fiber |
| Optical wavelength | 1310 nm |
| Maximum fiber distance | 20 km |
| Transmission modes | Store and forward, cut through, smart pass through and pass through via DIP switches |
| Link functions | Link Fault Pass-through; IEEE 802.3x flow control |
| Power input | 5V DC, 2A |
| Dimensions (W × D × H) | 71 × 94 × 26 mm |
| Operating environment | −10–55°C; 5–90% RH, non-condensing |
| Storage temperature | −40–75°C |
| Mounting | Desktop or compatible CVH-2000 chassis |
| Included | Converter, power adapter, quick installation guide |
| Optional | CVH-2000 media converter chassis |
| Net product weight | 0.42 kg |
| Store warranty | 3 YEARS WARRANTY |
Key Features
- Connect copper Gigabit Ethernet equipment to single-mode SC fiber.
- Reach up to 20 km over a suitable optical link.
- Monitor link loss with Link Fault Pass-through.
- Choose the transmission mode with DIP switches.
- Deploy with the included adapter or an optional compatible chassis.
Product Information
GVT-2002 carries a Gigabit Ethernet connection from copper to a 1310 nm single-mode SC fiber link. It is intended for longer network runs with matching far-end optics. Its copper port negotiates 10, 100 or 1000Mbps, while DIP switches select the transmission method and LFP behavior. The official version 1 datasheet contains conflicting frame-size and optical-standard labels; those disputed values are omitted here.
