Technical Specifications
| Specification | Details |
|---|---|
| Brand | Molex |
| Product Range | PowerCat 6 |
| Part Number | CAA-00340 |
| Product Type | Underground / Outdoor OSP Network Cable |
| Cable Category | Category 6 |
| Cable Construction | U/UTP |
| Number of Pairs | 4 Pair |
| Conductor Type | Solid Bare Annealed Copper |
| Conductor Size | 23 AWG / 0.58 mm |
| Primary Insulation | HDPE |
| Water Protection | Gel-Filled Construction |
| Inner Sheath | PE (UV Resistant) |
| Outer Sheath | Nylon |
| Nominal Overall Diameter | 6.1 mm |
| Cable Length | 305 Metres |
| Cable Colour | Blue |
| UV Resistant | Yes |
| Outdoor Use | Yes |
| Underground Use | Yes |
| Operating Temperature | -20°C to +75°C |
| Nominal Velocity of Propagation (NVP) | 65% |
| Performance Frequency | Up to 250 MHz |
| PoE Support | IEEE 802.3bt Type 1–4 / Cisco UPoE+* |
| Commercial Standards | ANSI/TIA/EIA-568-C.2, ISO/IEC 11801, UL 444, AS/CA S008:2019 |
Key Features
- Original Molex PowerCat 6 cable
- Category 6 U/UTP construction
- 4-pair 23AWG solid copper conductors
- 305-metre cable length
- Water-resistant gel-filled construction
- Designed for outdoor and underground installations
- UV-resistant PE inner sheath
- Heavy-duty nylon outer jacket
- Enhanced protection against abrasion
- Nylon jacket provides additional protection against termites
- HDPE conductor insulation
- Suitable for demanding Outside Plant (OSP) applications
- Category 6 performance up to 250 MHz
- Operating temperature from -20°C to +75°C
- Supports compatible PoE applications according to Molex specifications
Recommended Applications
Suitable for outdoor LAN infrastructure, underground network cabling, building-to-building network links, commercial premises, industrial environments, campus networks, outdoor IP CCTV networks, access-point connectivity and other structured cabling installations where additional moisture, UV, abrasion and environmental protection is required.
Complete your cabling installation
Match cable category, shielding, connector type and installation requirements across the complete channel.
