Specifications
| Brand headquarters / origin | ORing / Taiwan |
|---|---|
| Model | IES-C1080 |
| Ports | 8 × 10/100BASE-T(X) RJ45; auto-MDI/MDI-X |
| Management | Unmanaged |
| MAC table | 1K addresses |
| Packet buffer | 448Kbits |
| Forwarding method | Store-and-forward |
| Flow control | IEEE 802.3x |
| Hardware controls | DIP switches for QoS and broadcast storm protection |
| Power input | Single 9.6–60V DC or 24V AC (18–30V AC) input; 2-pin terminal block |
| Consumption | 4W |
| Power protection | Overload current and reverse-polarity protection |
| Enclosure | IP40 |
| Dimensions (W × H × D) | 43.5 × 103 × 64mm |
| Operating temperature | −10 to +60°C |
| Storage temperature | −40 to +85°C |
| Operating humidity | 5–95% RH, non-condensing |
| Mounting | DIN rail |
| PoE | No PoE output |
| Store warranty | 3 YEARS WARRANTY |
Key Features
- Connect eight Fast Ethernet devices in a compact cabinet.
- Start forwarding without a software management setup.
- Select QoS and broadcast storm protection with DIP controls.
- Use supported DC or AC power for the installation.
- Mount the IP40 enclosure on a DIN rail.
Product Information
IES-C1080 is the eight-port model in the official IES-C1050/C1080 datasheet. It provides unmanaged 10/100Mbps Ethernet distribution with a 1K MAC table and 448K-bit packet buffer. Hardware QoS and broadcast-storm controls support simple industrial network installations.
This listing uses the unsuffixed IES-C1080 datasheet, because the current product page is now headed IES-C1080-L. Supply the switch from a compatible 9.6–60V DC or supported 24V AC source. It does not provide PoE power. Keep the installation within the documented −10–60°C range and protect the enclosure appropriately.
Complete your network connections
Network Patch Cords · Structured Cabling Buying Guide
Match cable performance to the installation and check the exact switch interfaces before choosing accessories.
