Specifications
| Video Input / Interfaces | VE812R: N/A; VE812T: 1 x HDMI Type A Female (Black) |
|---|---|
| Video Input / Impedance | VE812R: N/A; VE812T: 100 Ω |
| Video Input / Max. Distance | VE812R: N/A; VE812T: 3 m |
| Video Output / Interfaces | VE812R: 1 x HDMI Type A Female (Black); VE812T: N/A |
| Video Output / Impedance | VE812R: 100 Ω; VE812T: N/A |
| Video Output / Max. Distance | VE812R: 3 m; VE812T: N/A |
| Video / Max. Data Rate | VE812R: 10.2 Gbps (3.4 Gbps Per Lane); VE812T: 10.2 Gbps (3.4 Gbps Per Lane) |
| Video / Max. Pixel Clock | VE812R: Up to 340 MHz; VE812T: Up to 340 MHz |
| Video / Compliance | VE812R: HDMI (3D, Deep Color, 4K) HDCP2.2 Compatible Consumer Electronics Control (CEC); VE812T: HDMI (3D, Deep Color, 4K) HDCP2.2 Compatible Consumer Electronics Control (CEC) |
| Video / Max. Resolutions / Distance | VE812R: Up to 4K@70m (Cat 5e/6) / 100m (Cat 6a); 1080p@100m*4K supported: 4096 x 2160 / 3840 x 2160 @ 60Hz (4:2:0); 4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4); VE812T: Up to 4K@70m (Cat 5e/6) / 100m (Cat 6a); 1080p@100m*4K supported: 4096 x 2160 / 3840 x 2160 @ 60Hz (4:2:0); 4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4) |
| Audio / Input | VE812R: N/A; VE812T: 1 x HDMI Type A Female (Black) |
| Audio / Output | VE812R: 1 x HDMI Type A Female (Black); VE812T: N/A |
| Connectors / Power | VE812R: 1 x DC Jack; VE812T: 1 x DC Jack |
| Connectors / Power Consumption | VE812R: DC5.3V:5.06W:24BTUNote:● The measurement in Watts indicates the typical power consumption of the device with no external loading.● The measurement in BTU/h indicates the power consumption of the device when it is fully loaded.; VE812T: DC5.3V:2.22W:10BTUNote:● The measurement in Watts indicates the typical power consumption of the device with no external loading.● The measurement in BTU/h indicates the power consumption of the device when it is fully loaded. |
| Environmental / Operating Temperature | VE812R: 0 – 50°C; VE812T: 0 – 50°C |
| Environmental / Storage Temperature | VE812R: -20 – 60°C; VE812T: -20 – 60°C |
| Environmental / Humidity | VE812R: 0 – 80% RH, Non-Condensing; VE812T: 0 – 80% RH, Non-Condensing |
| Physical Properties / Housing | VE812R: Metal; VE812T: Metal |
| Physical Properties / Weight | VE812R: 0.41 kg ( 0.9 lb ); VE812T: 0.40 kg ( 0.88 lb ) |
| Physical Properties / Dimensions (L x W x H) | VE812R: 14.17 x 10.30 x 3.00 cm (5.58 x 4.06 x 1.18 in.); VE812T: 14.17 x 10.30 x 3.00 cm (5.58 x 4.06 x 1.18 in.) |
| Physical Properties / Carton Lot | VE812R: 5 pcs; VE812T: 5 pcs |
| Physical Properties / Note | For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format. |
| Brand headquarters | Taiwan (ATEN International; headquarters country, not a claim of manufacturing origin) |
| Store warranty | 3 YEARS WARRANTY |
| Included accessories | 1x VE812T HDMI HDBaseT Transmitter; 1x VE812R HDMI HDBaseT Receiver; 2x Power Adapters; 1x Mounting Kit; 1x User Instructions |
Key Features
- Deploy with both transmitter and receiver included.
- Carry supported 4K HDMI content over HDBaseT.
- Reach up to 100 m with the specified cable and video format.
- Retain compatible HDMI audio and CEC communication.
- Install without additional source-device software.
Product Information
Extend an HDMI source to a remote display over a single HDBaseT cable using the included transmitter and receiver. This is a point-to-point AV link suited to installed presentation, signage and display systems.
4K reaches up to 70 m with Cat 5e/6 and 100 m with Cat 6a under the documented conditions. Each unit requires its own power adapter. Follow the exact resolution, chroma and cable specifications below. Confirm the source, display, cable type and supported signal timing before installation. Use the power arrangement and operating environment stated in the specifications.
Included in the manufacturer package: 1x VE812T HDMI HDBaseT Transmitter; 1x VE812R HDMI HDBaseT Receiver; 2x Power Adapters; 1x Mounting Kit; 1x User Instructions.
